Triton Stormwater Solution
Triton Stormwater Solutions is the premier provider of underground stormwater management systems. As the need to effectively manage stormwater has become a paramount issue around the world, it is essential to work with a company that has a customer. Service-minded business approach. At Triton, we have the experience to ensure successful results by providing superior products and service.
Features
Flexible: Modular system can be adapted to fit small drain fields can be used with or without catch basins and manifolds Double – or triple-stack capability proven since 2007 Online or perpendicular Main Header Row for inflow management.
Stronger: Exceeds ASHTO LERD Bridge Design Spec – 1 48,000-pound single-axle load-bearing capacity Bury up to 50,’ deep Designed to exceed ASTM F2418, F2787, f2922 standard and third-party performance testing.
Greener: Eco-friendly soy-based construction Carbon-neutral product can achieve up to 18 LEED credits Lightweight and easily nested chambers save fuel in shipping Filter options to target specific pollutants.
Cost Effective: Lower shipping costs fewer man-hours per cubic foot to install Soy-resin based – more stable pricing than competitor’s 120-year lifespan less stone required direct connections to top, front and side eliminate manifold systems and catch basins.
Easier to Install: Lightweight – allows one-person installation Three chambers can be installed in less than eight seconds Engineered connection allows easy placement of chamber sections.
SITE CONDITION FACTORS
LIGHTER
- 46% lighter per cubic foot of storage
- Chambers weigh just 32 pounds – a fraction of what the competition weighs
- Nest easily for ease of shipping and carrying
FLEXIBLE
- Modular system can be adapted to fit small drain fields
- Can be used with or without catch basins and manifolds
- Double- or triple-stack capability proven since 2007
- Inline or perpendicular Main Header Row for inflow management
STRONGER
- Exceeds ASHTO LFRD Bridge Design Spec 1
- 48,000-pound single-axle load-bearing capacity
- Bury up to 50′ deep
- H-30 Load Rating
- Designed to exceed ASTM F2418, F2787, F2922 standard and AASHTO LRFD Bridge specifications; all validated through third-party performance testing
GREENER
- Eco-friendly soy-based construction
- Carbon-neutral product
- Can achieve up to 18 LEED credits
- Lightweight and easily nested chambers save fuel in shipping
- Filter options to target specific pollutants
COST EFFECTIVE
- Lower shipping costs
- Fewer man-hours per cubic foot to install
- Soy-resin based – more stable pricing than competitors
- 120-year lifespan
- Less stone required
- Direct connections to top, front and side eliminate manifold systems and catch basins
EASIER TO INSTALL
- Lightweight – allows one-person installation
- Three chambers can be installed in less than eight seconds
- Engineered connection allows easy placement of chamber sections
- Direct connections to top, front and side
- Requires less stone and geofabric than competitive systems
L.E.E.D. CERTIFICATION
Note: Because of its eco-friendly attributes, Triton chambers can help a project achieve up to 18 credits from the Leadership in Energy and Environmental Design (LEED) Green Building Rating System. [Sustainable Sites – 5 credits; Water Efficiency – 5 credits; Materials and Resources – 4 credits; Innovation and Design process – 4 credits; Carbon neutrality – 3 credits).
